58W 400mA DC70-150V Auto dimming Radar Motion Sensor Driver for Street light batten Light LED Panel light Downlight
This driver is designed to provide efficient power management and control for various types of lighting fixtures. It integrates an advanced radar motion sensor and auto dimming capabilities, making it ideal for street lights, LED batten lights, LED panel lights, and LED downlights.
58W 400mA DC70-150V Auto dimming Radar Motion Sensor Driver for Street light batten Light LED Panel light Downlight
This driver is designed to provide efficient power management and control for various types of lighting fixtures. It integrates an advanced radar motion sensor and auto dimming capabilities, making it ideal for street lights, LED batten lights, LED panel lights, and LED downlights.
Features:
Power Output: 58W with a constant current of 400mA, suitable for a wide voltage range of DC70-150V.
Auto Dimming: Automatically adjusts brightness based on the presence of motion, enhancing energy efficiency and extending the lifespan of the light fixtures.
Radar Motion Sensor: Equipped with a radar motion sensor that detects movement and activates the light accordingly, providing security and convenience.
Compatibility: Compatible with various lighting applications including street lights, batten lights, LED panel lights, and downlights.
Energy Efficient: Reduces energy consumption by dimming the lights when no motion is detected.
Durable Design: Built to withstand various environmental conditions, ensuring long-term reliability and performance.
Easy Installation: Simple to install and integrate with existing lighting systems.
| Specification for 58W 400mA DC70-150V Auto dimming Radar Motion Sensor Driver for Street light batten Light LED Panel light | |
| Model no | AM-90XD60T |
| Operation voltage | 185-265Vac 50/60Hz |
| Output Power | 58W |
| Ouput voltage | DC70-150V |
| Output current | 400mA |
| Power factor | 0.5 |
| HF system | Option 1: 3.3GHz Option 2: 5.8GHz (Sensor distance can be adjustable) |
| Transmitting power | <0.5mW |
Control Light source type | On/Standby (100%-20%) On/Off (100%-0%) |
| Detection range | 6-8m radius |
| Detection angle | 180*360 degree |
Hold time (Default) | 15-20s （30s/60s/2mins/3mins set by factory) |
| IP rating | IP20 |
| Light source type | The radar motion sensor drivers are ideal for retrofit LED Panel light, LED Downlight, LED Ceiling light, LED Batten, LED Triproof light. LED Surface downlight etc. |
| Size(mm) | 60*35*20(with housing) |
| Application type | With motion sensor Corridor, staircase, lobby, balcony, hallway, |
| MOQ | 100pcs |
| Lead time | 1000pcs: 7 days 5000pcs: 15-20 days (depending on required specification) |
Application type:
LED Batten, LED Downlight, LED Linear light, LED ceiling light. LED Batten, LED street light
FAQ:
1. What are the advantages of using a microwave radar sensor LED driver?
Microwave radar sensors have a wider coverage area compared to traditional infrared sensors, making them suitable for large spaces.
They can penetrate obstacles like glass and plastic, allowing concealed installation.
Radar sensors are less affected by environmental factors like temperature and humidity.
LED drivers with radar sensors can provide intelligent lighting control, saving energy and increasing efficiency.
2. How does the microwave radar sensor work?
